Best Price black mono solar panels mini 30W Solar Panels Use Mobile Charge
Product Specification
| Characteristics | SN-M030W |
| Maximum Power(Pmax) | 30Wp |
| Optimum Operating Voltage/Vmp | 18.0V |
| Optimum Operating Current/Imp | 1.67A |
| Open Circuit Voltage /Voc | 21.6V |
| Short Circuit Current /Isc | 1.87A |
| Module Efficiency | 13.70% |
| Weight | 2.8Kg |
| Numbers of cells | 36(2*18) |
| Cell dimension(mm) | 156*31.2 |
| Dimensions(mm) | 635*345*25 |
| | SN-M005 | SN-M010 | SN-M030 | SN-M040 | SN-M050 | SN-M060 | SN-M080 |
| MP/W | 5 | 10 | 30 | 40 | 50 | 60 | 80 |
| VMP/V | 18 | 18 | 18 | 18 | 18 | 18 | 18 |
| IMP/A | 0.28 | 0.56 | 1.67 | 2.22 | 2.78 | 3.33 | 4.4 |
| VOC/V | 21.6 | 21.6 | 21.6 | 21.6 | 21.6 | 21.6 | 21.6 |
| ISC/A | 0.31 | 0.66 | 1.87 | 2.42 | 2.98 | 3.52 | 4.64 |
| Weight/Kg | 1 | 1.8 | 2.8 | 3.2 | 4 | 5.2 | 6 |
| Number of cells | 36 | 36 | 36 | 36 | 36 | 36 | 36 |
| Cell efficiency | 18.11% | 17.80% | 18.22% | 18.34% | 17.96% | 17.64% | 18.21% |
| Module efficiency | 10.32% | 12.88% | 13.69% | 14.80% | 14.42% | 14.21% | 15.61% |
| Cell dimension(mm) | 78*10.4 | 78*19.5 | 156*31.2 | 156*39 | 156*52 | 156*62.4 | 156*78 |
| Dimensions(mm) | 255*190*18 | 345*225*18 | 635*345*25 | 530*510*25 | 680*510*30 | 670*630*30 | 765*670*30 |
PS: Customized for size, wattage, voltage, connectors.
Application Scope
Courtyard lighting.
Small household lighting system.
Street lighting.
Portable solar power.
All small power electrical devices & small PV system.
Shine Solar Products Limited Warranty
10 Years Manufacturing warranty.
12 years warranty 90% power output.
25 years warranty 80% power output.
Our services:
Q:What's the sample cost ?
Samples charge is according to actual cost, and it is refundable after your order released.
Q:How about the delivery time?
Sample needs 3-5 days, mass production time needs 10 days for order.
Q. How to apply refund?
A. Once the PI has been confirmed and ordered goods are ready, a refund will not available for a canceled order. But a refund would back to you in time the case that we could not offer the products required in stock due to the shortage or unavailability.
Q. Can I come visit your showroom and factory?
1) Welcome to visit our office and shop directly before establishing long-term business relationship.
2) We'd very like to help you book the hotel and pick you up from the airport, or the railway station. Please inform us if you have any scheduling in China.
3) Many clients from India, Myanmar, Germany, Saudi Arab, France, Russia etc has paid a visit in our showroom, so now, is your turn?
Product Tags:
|
|
30 Watt Mono Cell Solar Panel Flexible Portable IP67 Junction Box With Diodes Images
|
